NEO-M8Q-0

u-blox M8 GNSS Module*TCXO*ROM*LCC 12x16mm*250 pcs/reel
Manufacturer Item No.:
NEO-M8Q-0
Item number:
NEO-M8Q-0
from 1 pieces 25,87 € / 1 pieces
from 10 pieces 22,17 € / 1 pieces
from 50 pieces 19,90 € / 1 pieces
from 100 pieces 15,84 € / 1 pieces
25,87 € / 1 pieces
Orderable, delivery time approx. 8 weeks
plus Shipping and VAT
Usually ships in 1 to 3 days
Add to Favorites

Versatile GNSS modules in different variants for easy manufacturing

  • Concurrent reception of up to 3 GNSS (GPS, Galileo, GLONASS, BeiDou)
  • Industry leading 167 dBm navigation sensitivity
  • Security and integrity protection
  • Supports all satellite augmentation systems
  • Advanced jamming and spoofing detection
  • Product variants to meet performance and cost requirements
  • Backward compatible with NEO-7 and NEO-6 families
Form factor:NEO
Chip:u-blox M8
GNSS supported:BeiDou, Galileo, GLONASS, GPS / QZSS
GNSS Bands:L1
GNSS Oscillator:TCXO
Memory:ROM
Antenna Option:Antenna pin
Temperature:-40 to +85 °C
Dimensions:16 x 12.2 x 2.4 mm
Voltage:2.7 - 3.6 VDC
UART:1
USB:1
I2C:1
SPI:1
S/W Features:Active antenna / LNA control, Additional LNA, Additional SAW, RTC crystal
