NEO-M8N-0
u-blox M8 GNSS Module*TCXO*Flash*SAW*LNA* LCC*12x16mm*250 pcs/reel
Manufacturer Item No.:
NEO-M8N-0
Item number:
NEO-M8N-0
from 1 pieces
29,37 € / 1 pieces
from 10 pieces
25,17 € / 1 pieces
from 50 pieces
22,59 € / 1 pieces
from 100 pieces
17,98 € / 1 pieces
Add to Favorites
Versatile GNSS modules in different variants for easy manufacturing
- Concurrent reception of up to 3 GNSS (GPS, Galileo, GLONASS, BeiDou)
- Industry leading 167 dBm navigation sensitivity
- Security and integrity protection
- Supports all satellite augmentation systems
- Advanced jamming and spoofing detection
- Product variants to meet performance and cost requirements
- Backward compatible with NEO-7 and NEO-6 families
| Form factor: | NEO |
|---|---|
| Chip: | u-blox M8 |
| GNSS supported: | GPS / QZSS, Galileo, BeiDou, GLONASS |
| GNSS Bands: | L1 |
| GNSS Oscillator: | TCXO |
| Memory: | Flash |
| Antenna Option: | Antenna pin |
| Temperature: | -40 to +85 °C |
| Dimensions: | 16 x 12.2 x 2.4 mm |
| Voltage: | 2.7 - 3.6 VDC |
| UART: | 1 |
| USB: | 1 |
| I2C: | 1 |
| SPI: | 1 |
| S/W Features: | Active antenna / LNA control, Additional LNA, Additional SAW, RTC crystal |
