NORA-W401-00B

u-blox*Multiradio stand-alone mod.*4MB Flash
open CPU*ant. pin*ESP32-C6*10.4x14.3x1.9mm

SOP: Q1/2025 (please contact us for early samples)
Manufacturer Item No.:
NORA-W401-00B
Item number:
NORA-W401-00B
Choose Variant:
NORA-W401-00B
NORA-W401-00B
NORA-W401-10B
Currently not available
Add to Favorites

Stand-alone Wi-Fi 6 multiradio modules

Wireless MCU modules for cost-efficient designs
  • Single-band Wi-Fi 6, Bluetooth Low Energy 5.3, Zigbee, and Thread
  • Supports Wi-Fi 6 Target Wake Time and other low power peripherals
  • Full set of enhanced security features
  • Small footprint, multiple antenna options, pin compatible with other NORA modules
  • Matter over Wi-Fi or Thread
  • Global certification
Form factor:NORA
Wi-Fi Standard:Wi-Fi 6 single-band
Bluetooth Standard:v5.3 (Bluetooth Low Energy)
Antenna Option:Antenna pin
Type :stand-alone
Software:openCPU
Chip:ESP32-C6
RAM:512 kBytes
Flash:4096 kByte
UART:1
I2C:1
SDIO:1
SPI:1
GPIO:22
Voltage:3.0 to 3.6 VDC
Temperature:-40 to +85 °C
Dimensions:14.3 x 10.4 x 1.9 mm
