Product description
The CMX7032 is a highly integrated baseband signalling processor ICs that fulfill the requirement of an SOTDMA and CSTDMA AIS transceiver, dual AIS Receive only device and exactTrax and exactSeNS long range AIS Class-B tracking.
This device provides a quick route to developing an AIS based system and getting to market fast. Embedding much of the AIS, DSC and exactTrax protocol ensures minimal host involvement, therefore the designer can concentrate on the overall end application. Built on FirmASIC® technology, the CMX7032 provides the ultimate flexibility when designing Marine AIS based systems. The latest function image adds support for exactEarths new exactSeNS service. This provides a data payload capability within dedicated ASM-based messages transmitted using sophisticated encoding to support reliable reception via satellite and provides a core building block to enable the expansion of Marine IoT solutions.
Features
- GMSK and FSK Modem
- Marine AIS and DSC data formatting
- exactTrax and exactSeNS long range operation and formatting
- Supports CSTDMA/SOTDMA operation
- Optimum co-channel performance
- Two flexible Integer-N Synthesisers (CMX7032 only)
- Two synthesised PLL clocks
- Limiter-discriminator Rx interface
Voltage: | 3.0 to 3.6 VDC |
---|---|
Form factor: | 64-pin LQFP |
Temperature: | -40 to +85 °C |
Dimensions: | 11.8 x 11.8 x 1.4 mm |
Packaging: | Tray |
Reference Frequency Input: | 9.6 or 19.2 MHz |
On-Chip PLL: | yes |
On-chip VCO: | yes |
Duplex Mode: | Half Duplex |
UART: | 1 |
FirmASIC Function Image: | yes |
NMEA 0183: | yes |
AIS SOTDMA: | yes |
AIS CSTDMA: | yes |
EEPROM SPI Port: | 1 |
