CAM-M8C-0-10
u-blox M8 GNSS Antenna Module*ROM*Crystal SAW*1.65-3.6V*9.6 x 14.0mm*500 pcs/reel
Manufacturer Item No.:
CAM-M8C-0-10
Item number:
CAM-M8C-0
from 1 pieces
20,33 € / 1 pieces
from 10 pieces
17,43 € / 1 pieces
from 50 pieces
15,64 € / 1 pieces
from 100 pieces
12,45 € / 1 pieces
from 250 pieces
10,17 € / 1 pieces
Add to Favorites
Smart antenna module for omnidirectional GNSS reception
- Concurrent reception of up to 3 GNSS (GPS, Galileo, GLONASS, BeiDou)
- Miniature size and weight with low power consumption
- Embedded, omnidirectional and wideband antenna
- Industry leading 167 dBm navigation sensitivity
- Optional external antenna
- Product variants to meet performance and cost requirements
| Form factor: | CAM |
|---|---|
| Chip: | u-blox M8 |
| GNSS supported: | GPS / QZSS, Galileo, BeiDou, GLONASS |
| GNSS Bands: | L1 |
| GNSS Oscillator: | Crystal |
| Memory: | ROM |
| Antenna Option: | Internal antenna |
| Temperature: | -40 to +85 °C |
| Dimensions: | 14 x 9.6 x 1.95 mm |
| Voltage: | 1.65 - 3.6 VDC |
| UART: | 1 |
| I2C: | 1 |
| SPI: | 1 |
| S/W Features: | Additional LNA, Additional SAW, Built-in sensor, RTC crystal |
