GNSS L1 / L5 Active Stacked Patch Antenna
The Taoglas Accura AGVLB.25A is a multi-band GPS, GLONASS, BeiDou/Compass and IRNSS, high-performance GNSS L1 / L5 Active Stacked Patch Antenna for high precision GNSS accuracy and fast positioning. It utilizes a 25*25*8mm advanced dual-stacked ceramic patch antenna with optimized gain for GPS L1/L5, GLONASS, Galileo, IRNSS and BeiDou bands. Integration of IRNSS allows for better navigation accuracy and enables compliance with AIS-140 for tracking devices in India.The AGVLB.25A has been designed for in-device mounting with a small size of just 25*25*12mm, it can fit in some of the most compact devices.
This compact antenna exhibits excellent radiation patterns on both GPS L1/L5 bands and with a low noise figure to preserve signal quality helps minimize time to first fix. It also features excellent out-of-band rejection to prevent out-of-band signals from overdriving or damaging its LNAs.
Typical Applications Include:
- RTK - Wearables - Transportation - Agriculture
- Navigation - Security - Autonomous Vehicles
The AGVLB.25A has been tuned and tested on a 70 x 70 mm ground plane and exhibits omnidirectional radiation patterns at both bands.
RF Technology: | active GNSS |
---|---|
Form factor: | Embedded Antennas |
RF Bands: | L1 / L5 |
Connector: | IPEX MHFI (U.FL) |
Cable length: | 60 |
Dimensions: | 25 x 25 x 11.92mm |
Temperature: | -40 to +80 °C |
VSWR: | 2 |
Gain: | 2.9 dBi |
