SARA-R422S-01B

u-blox*LTE Cat M1/NB2/2G module*band configurable
secure cloud*16x26mm*LGA*250pcs/reel

Use restriction: 4G M2M
IPR coverage: Premium
Manufacturer Item No.:
SARA-R422S-01B
Item number:
SARA-R422S-01B
Choose Variant:
SARA-R422S-01B
SARA-R422S-01B
SARA-R422S-00B
from 1 pieces 31,14 € / 1 pieces
from 10 pieces 24,22 € / 1 pieces
from 50 pieces 19,82 € / 1 pieces
from 100 pieces 18,17 € / 1 pieces
31,14 € / 1 pieces
In Stock.
plus Shipping and VAT
Usually ships in 1 to 3 days
Add to Favorites

Built-in foundation and end-to-end security with root of trust

  • Power autonomy through positioning in the cloud; integrated u-blox M10 GNSS receiver and CloudLocate
  • Software-based configurability within each hardware design
  • Simultaneous LTE communication with GNSS positioning
  • Guaranteed best coverage with 23 dBm output power
  • Cost-effective, power efficient, end-to-end IoT communication with MQTT Anywhere and MQTT Flex
Form factor:SARA
Voltage:3.2 - 4.5 VDC
Cellular Regions:Multi-Region
LTE Bands:1, 12, 13, 18, 19, 2, 20, 25, 26, 28, 3, 4, 5, 66, 8, 85
LTE power class:23 dBm
GSM Bands:Quad-band
Datarate:M1 (588 kbit/s DL and 1119 kbit/s UL), NB2 (127 kbit/s DL and 158.5 kbit/s UL)
Temperature:-40 to +85 °C
Dimensions:26 x 16 x 2.5 mm
UART:2
USB:1 (for diagnostics)
I2C:1
GPIO:6
