MIA-M10C-00B
u-blox M10 GNSS SiP*Crystal*ROM*1,8VDC*S-LGA 53*4,5x4,5mm*1000 pcs/reel
order 20 pieces for a full sample tray
order 20 pieces for a full sample tray
Manufacturer Item No.:
MIA-M10C-00B
Item number:
MIA-M10C-00B
from 20 pieces
8,89 € / 1 pieces
from 100 pieces
6,22 € / 1 pieces
from 500 pieces
4,78 € / 1 pieces
Add to Favorites
- 4.5 x 4.5 mm chip-sized module requiring no external components
- Less than 25 mW power consumption without compromising GNSS performance
- Twice the battery life by leveraging optimized power save modes
- Maximum position availability with concurrent reception of 4 GNSS
- Proven excellent performance, even with small antennas
| Form factor: | MIA |
|---|---|
| Chip: | u-blox M10 |
| GNSS supported: | GPS / QZSS, Galileo, BeiDou, GLONASS |
| GNSS Bands: | L1 |
| GNSS Oscillator: | Crystal |
| Memory: | ROM |
| Antenna Option: | Antenna pin |
| Dimensions: | 4.5 x 4.5 x 1 mm |
| Temperature: | -40 to +85 °C |
| Voltage: | 1.76 - 3.6 VDC |
| I2C: | 1 |
| UART: | 1 |
Item News
u-blox
| Area | Standard Lead Time | Allocation | |
|---|---|---|---|
|
u-blox GNSS SiP Modules
MIA, ZOE, EVA
Allocation: no
|
MIA, ZOE, EVA | 12-16 weeks | no |
