Alternatives for EOL Mitsubishi Displays from WINSTAR in Sizes 8.4inch and 10.4inch
Files
WINSTAR released 2 new displays to replace EOL displays from Mitsubishi. Both displays come with a wide viewing angle due to it’s IPS technology.
More details, pricing and lead time can be requested at displays@spezial.com
Alternative Displays Overview
| Original Display | Alternative Display |
| 8.4 inch AA084XB01 | WF0840ATWAMLNN0 WF104GTWAMLNB0 (PCAP) WF104GTWAMLNN0 (without PCAP) |
| 10.4 inch AA104XF12 | WF104GSWAMLNN0 (High Bright, without PCAP) |
Technical data
| Size | 8.4 inch | 10.4 inch |
| Type | IPS | IPS |
| Resolution | 1024x768 | 1024x768 |
| Brightness | 500 cd/m² | 400 cd/m² |
| Viewing Angle | 80/80/80/80 | 80/80/80/80 |
| Interface | LVDS | LVDS |
| Operating Temperature | -30°C to +80°C | -30°C to +80°C |
| Touch | optional | PCAP |
| Touch Interface | - | USB |
More details, pricing and lead time can be requested at displays@spezial.com
