The new NovaSensors NPC-1210 series are a quick replacement for most TE 12XX, 56XX and 58XX series and are available now. This series of low/medium pressure sensors offer a cost-effective solution for calibrated applications requiring a wide temperature range. In a dual-in-line (DIP) package, the NPC-1210 series is ideal for traditional PCB applications. Additional optional pressure port and pin layout configurations offer maximum flexibility in low-profile applications where tube port orientation is critical.
The NPC-1210 series is based on NovaSens advanced piezoresistive sensor technology SenStable®. These silicon micromachining techniques are used to implement piezo-resistive strain gauges as ion implants in a Wheatstone bridge configuration. Furthermore, these sensors are superior in the compensated operating temperature range of 32°F to 140°F (0°C to 60°C). A gain set resistor is included to regulate the FSO for field interchangeability.
Investments in tooling, capacity and supply chain ensure this product will be manufactured for years to come!
The NPC-1210 series is based on NovaSens advanced piezoresistive sensor technology SenStable®. These silicon micromachining techniques are used to implement piezo-resistive strain gauges as ion implants in a Wheatstone bridge configuration. Furthermore, these sensors are superior in the compensated operating temperature range of 32°F to 140°F (0°C to 60°C). A gain set resistor is included to regulate the FSO for field interchangeability.
Investments in tooling, capacity and supply chain ensure this product will be manufactured for years to come!
Features
Applications
- High sensitivity
- High accuracy
- Interchangeable
- Temperature compensated: 0°C to 60°C (32°F to 140°F)
- Dual-in-line configuration (DIP) package
- High semiconductor reliability
- Individual traceability
Applications
- Industrial automation
- Airflow monitoring
- Process control
- Medical equipment
- Underground cable leak detection
- Ventilation
- Airway monitoring
