SECO: SOM-COMe-CT6-Snapdragon-X - Snapdragon X COM Express Module Powers Edge AI
Snapdragon X COM Express Module Powers Edge AI
SE Spezial-Electronic GmbH introduces the SOM-COMe-CT6-Snapdragon-X, a COM Express 3.1 Type 6 Compact module powered by Qualcomm Snapdragon X processors. This high-performance module drives innovation in edge AI for industries like automotive, IoT, and industrial automation, with SE Spezial-Electronic offering expert consulting and tailored solutions.Technical Features Overview
The SOM-COMe-CT6-Snapdragon-X is available in multiple configurations, each designed for demanding edge applications. The table below summarizes the key specifications of its processor variants:
| Feature | Snapdragon X (X1-26-100) |
Snapdragon X Plus (X1P-42-100) |
Snapdragon X Plus (X1P-64-100) |
Snapdragon X Elite (X1E-78-100) |
| Cores | 8 (3.0 GHz) | 8 (3.4 GHz) | 10 (3.4 GHz) | 12 (3.4 GHz) |
| NPU Performance | Up to 45 TOPS | Up to 45 TOPS | Up to 45 TOPS | Up to 45 TOPS |
| GPU (Adreno) | 1.7 TFLOPS | 1.7 TFLOPS | 3.8 TFLOPS | 3.8 TFLOPS |
| Memory | Up to 64 GB LPDDR5 (4224 MT/s) | Up to 64 GB LPDDR5 (4224 MT/s) | Up to 64 GB LPDDR5 (4224 MT/s) | Up to 64 GB LPDDR5 (4224 MT/s) |
| Temperature Range | Commercial / Industrial | Commercial / Industrial | Commercial / Industrial | Commercial / Industrial |
High-Performance Edge Computing
Powered by Qualcomm’s Snapdragon X series, the module integrates a Hexagon NPU delivering up to 45 TOPS for AI tasks like real-time analytics and machine learning. Its compact 95x95 mm form factor and support for Windows 11 IoT Enterprise ensure seamless integration into custom systems.
Versatile Connectivity and Graphics
The module supports up to four displays (DP, eDP, or LVDS) with resolutions up to 5120x2880 at 60 Hz. Connectivity includes one NBase-T Ethernet (up to 2.5 Gbps), USB4 Gen3x2, PCIe Gen4, and onboard UFS 4.0 storage (up to 256 GB). These features make it ideal for IoT, automotive, and medical applications.
Industry Applications
- Industrial Automation: Enables AI-driven control and monitoring.
- Automotive: Supports ADAS and infotainment systems.
- IoT: Powers smart devices with robust connectivity.
- Medical: Facilitates high-resolution imaging and diagnostics.
The SOM-COMe-CT6-Snapdragon-X delivers cutting-edge AI and connectivity for edge applications. Contact us to learn more.
Key Highlights
- AI Acceleration: Qualcomm Hexagon NPU with up to 45 TOPS for real-time inference and machine learning.
- CPU Power: Up to 12 Oryon cores @ 3.4 GHz, optimized for multi-threaded workloads.
- GPU Performance: Adreno graphics with up to 3.8 TFLOPS FP32 for advanced visualization.
- Memory: Up to 64 GB LPDDR5 @ 4224 MT/s in SiP for blazing fast data throughput.
- Display Support: Up to 4 independent 5K/4K displays for multi-screen applications.
- High-Speed Connectivity: USB4 Gen3x2, PCIe Gen4, and 2.5 GbE with TSN for industrial networking.
- Rugged Design: Industrial temperature range –40 °C to +85 °C.
