Introducing the Han® S 450 Plus — The Next-Generation Connector for High-Performance Energy Storage Systems
Files
Our Partner HARTING is excited to unveil the Han® S 450 Plus, a powerful and reliable connector designed to meet the growing demands of today’s advanced energy storage systems (ESS). With significantly enhanced power handling and a rugged design, this latest addition to the Han® S series sets a new benchmark for ESS connectivity.
Built for High-Power Applications
Energy storage applications require compact interfaces capable of transmitting large currents with minimal heat generation. The Han® S 450 Plus rises to the challenge, boosting the nominal current capacity from the previous 200 A up to an impressive 500 A at 2,000 VDC. This makes it ideal for faster charging and discharging cycles in modern battery storage systems.
To accommodate varied installation needs, HARTING offers three housing sizes supporting different conductor cross-sections:
Lab testing has already shown excellent performance with a 150 mm² contact handling 500 A without overheating, proving the connector’s readiness for high-demand environments.
Built for High-Power Applications
Energy storage applications require compact interfaces capable of transmitting large currents with minimal heat generation. The Han® S 450 Plus rises to the challenge, boosting the nominal current capacity from the previous 200 A up to an impressive 500 A at 2,000 VDC. This makes it ideal for faster charging and discharging cycles in modern battery storage systems.
To accommodate varied installation needs, HARTING offers three housing sizes supporting different conductor cross-sections:
- 95 mm² (AWG 3/0 or 4/0): up to 350 A
- 120 mm² (250 kcmil): up to 400 A
- 150 mm² (300 kcmil): up to 450 A
Lab testing has already shown excellent performance with a 150 mm² contact handling 500 A without overheating, proving the connector’s readiness for high-demand environments.
Beyond raw power, the Han® S 450 Plus excels in reliability and practical handling:
The Han® S 450 Plus not only delivers high electrical performance but also offers the robustness and flexibility needed in evolving ESS applications, from large-scale stationary storage to mobile systems requiring vibration resistance and secure, error-proof connections.
Experience the Han® S 450 Plus for yourself. Request a product sample today and see how cutting-edge connector technology can power your next energy storage project. Contact your SE Key Account Manager or send us an email at vertrieb@spezial.com.
- 360° rotation on the input side allows flexible cable positioning and easier module configuration
- Built to withstand up to 500 mating cycles, ensuring long-term durability
- A double locking system and multiple coding options eliminate connection errors and make installation straightforward
- Clear color coding (red, black, blue, orange) ensures unmistakable identification of polarity and function
The Han® S 450 Plus not only delivers high electrical performance but also offers the robustness and flexibility needed in evolving ESS applications, from large-scale stationary storage to mobile systems requiring vibration resistance and secure, error-proof connections.
Experience the Han® S 450 Plus for yourself. Request a product sample today and see how cutting-edge connector technology can power your next energy storage project. Contact your SE Key Account Manager or send us an email at vertrieb@spezial.com.
